RZ/A2M SUB Board RTK79210XXB00000BE 1. Overview
R20UT4398EJ0100 Rev.1.00 1-3
2018.10.11
1.3 Features
Table 1.1 shows an overview of RTK79210XXB00000BE specifications.
Table 1.1 Features of RTK79210XXB00000BE
No.
item
details
1
Memory
• SDRAM: 64 MBytes ×1
‐ ISSI S42S16320F-7TL
• EEPROM: 16 KBytes ×1
‐ Renesas R1EX24128ASAS0A
• NAND flash memory: 128 MBytes ×1 is possible to mount on the board pattern.
‐ Cypress S34ML01G100TFI000
2
Connector
• CPU board connector (204-pin): 1
• DRP connector (40-pin): 1
• Audio input/output mini jack (3,5 ϕ): 2
• Serial port connector (USB Micro-B): 1
• LAN connector (RJ-45): 2
• SD card slot: 1
• USB Series A receptacle: 1
• USB Mini-B receptacle: 1
• CMOS camera connector: 1
• RZ/A2M VDC6 digital image signal input/output MIL connector (50-pin): 1
• RZ/A2M LVDS digital image signal output connector (20-pin): 1
• RZ/A2M LVDS back light connector (6-pin): 1
• DC power jack: 1
3
Switch
• Power switch: 1
• User switch: 2 (NMI, IRQ0)
• Key input switch: 2
• DIP switch: 1 (I/F settings)
4
Outer
dimensions/layered
configuration
• Dimensions: 105 x 148mm
• Implementation: 4 level dual surface, board thickness: 1.6mm
• Circuit board configuration: Single board
