Renesas RTK79210**B00000BE User Manual

RZ/A2M SUB Board RTK79210XXB00000BE 2. Function specifications
R20UT4398EJ0100 Rev.1.00 2-30
2018.10.11
Table 2.7.1 Function Setting Table of DIP Switches SW6-4 and SW6-6 for System Setting
DIP
Switch
Function
ON
OFF
SW6-4
P6_1 is used as RMII_TXDEN pin.
P6_1 is used as VIO_CLK input pin.
*1
(default setting)
SW6-6
PJ_6 is used as LCD0_CLK output pin.
PJ_7 is used as LCD0_EXTCLK input pin.
(default setting)
PJ_6 is used as FCE pin.
PJ_7 is used as NAF0 pin.
[Note] indicates setting functions.
*1 When using P6_1 as VIO_CLK input pin, an oscillator must be equipped to X6.
There is no reverse insertion guard on the oscillator socket, so be careful to insert in the direction of pin 1 when
connecting.
