RZ/A2M SUB Board RTK79210XXB00000BE 3. Operating specifications
R20UT4398EJ0100 Rev.1.00 3-19
2018.10.11
Table 3.1.14 Digital Image Input/output Connector (CN15) Pin Layout Table
Pin
Signal name
Pin
Signal name
1
DATA0 (PF_7 / DV0_DATA23 / LCD0_DATA0)
2
DATA1 (PH_2 / DV0_DATA22 / LCD0_DATA1)
3
DATA2 (PF_6 / DV0_DATA21 / LCD0_DATA2)
4
DATA3 (PF_5 / DV0_DATA20 / LCD0_DATA3)
5
DATA4 (PF_4 / DV0_DATA19 / LCD0_DATA4)
6
DATA5 (PF_3 / DV0_DATA18 / LCD0_DATA5)
7
DATA6 (PF_2 / DV0_DATA17 / LCD0_DATA6)
8
DATA7 (PF_1 / DV0_DATA16 / LCD0_DATA7)
9
DATA8 (PF_0 / DV0_DATA15 / LCD0_DATA8)
10
DATA9 (P8_0 / DV0_DATA14 / LCD0_DATA9)
11
DATA10 (PA_0 / DV0_DATA13 / LCD0_DATA10)
12
DATA11 (PA_1 / DV0_DATA12 / LCD0_DATA11)
13
DATA12 (PA_2 / DV0_DATA11 / LCD0_DATA12)
14
DATA13 (PA_3 / DV0_DATA10 / LCD0_DATA13)
15
DATA14 (PA_4 / DV0_DATA9 / LCD0_DATA14)
16
DATA15 (PA_5 / DV0_DATA8 / LCD0_DATA15)
17
DATA16 (PA_6 / DV0_DATA7 / LCD0_DATA16)
18
DATA17 (PA_7 / DV0_DATA6 / LCD0_DATA17)
19
DATA18 (PB_0 / DV0_DATA5 / LCD0_DATA18)
20
DATA19 (PB_1 / DV0_DATA4 / LCD0_DATA19)
21
DATA20 (PB_2 / DV0_DATA3 / LCD0_DATA20)
22
DATA21 (PB_3 / DV0_DATA2 / LCD0_DATA21)
23
DATA22 (PB_4 / DV0_DATA1 / LCD0_DATA22)
24
DATA23 (PB_5 / DV0_DATA0 / LCD0_DATA23)
25
RESET (RES#)
26
LCD_CLK (PJ_6 / FCE / LCD0_CLK)
27
TCON1 (PC_3 / LCD0_TCON4)
28
TCON2 (PC_4 / LCD0_TCON3)
29
TCON3 (P7_7 / DV0_HSYNC / LCD0_TCON0)
30
Hi (DITHB) (connects to +3.3V via 10kΩ resistor)
DV_HSYNC (P7_7 / DV0_HSYNC /
LCD0_TCON0)
31
Hi (MODE) (connects to +3.3V via 10kΩ resistor)
32
Hi (L/R) (connects to +3.3V via 10kΩ resistor)
33
Low (U/D) (connects to Vss via 10kΩ resistor)
34
PWM (P7_6 / DV0_VSYNC / GTIOC3A)
DV_VSYNC (P7_6 / DV0_VSYNC / GTIOC3A)
35
NC
36
NC
37
SDA (PD_7 / RIIC3SDA)
38
SCL (PD_6 / RIIC3SCL)
39
TP_INT (P5_7 / IRQ3)
40
NC
41
NC
42
NC
43
NC
44
DV_CLK (P7_2 / DV0_CLK)
45
Vcc (+3.3V)
46
Vcc (+3.3V)
47
GND (Vss)
48
GND (Vss)
49
5V (+5V)
50
5V (+5V)
[Note] Red characters indicate functions in use.
