Renfert BASIC eco - 3 Product Description; General Description; Components and Functional Elements

EN
1 Hand sleeves
2 Base grid
3 Selector switch (only on the 2 tanks version)
4 ON / OFF switch (lighting)
5 Tank lid
6 Pressure regulator
7 Pressure gauge
8 Protection screen
9 Hand piece
10 Foot switch
11 Compressed air tube
12 Power cord
13 Foot switch connection (A)
(push-in connection)
3. Product description
3.1 General description
In a laboratory, the sandblasting unit is used to remove investment material deposits, oxides on cast met-
al objects and for conditioning surfaces.
The sandblasting unit is available in a 1 tank and 2 tank version. The 1 tank version can be upgraded with
a second tank (see accessories) to a 2 tank version.
3.2 Components and functional elements
Fig. 1
2
3
1
5
6
7
8
4
9
20
19
21
17
16
15
18
22
20
13
14
12
24
23
11
10
14 Air connection (push-in connection)
15 Sandblasting tank
16 Mixing chamber
17 Filter cartridge (push-in connection)
18 Suction tube
19 Foot switch connection (B)
(push-in connection)
20 Water trap valve
21 Water trap
22 Foot switch connection (B)
(push-in connection)
(only on the 1 tank version)
23 Dosing nipple tool
24 Connection set
