Renishaw PH20 - Technical data MCR20 NI and MCR20 module change rack

TechnicaldataMCR20NIandMCR20modulechange
rack
Parameters MCR20NI MCR20
Length 200 mm 200 mm
Width 60 mm 60 mm
Height 145 mm 145 mm
Port entry
velocity
Maximum 800 mm/s Maximum 800 mm/s
Mounting
orientation
Not designed for horizontal operation with
the ports in a vertical orientation
Not designed for horizontal operation with
the ports in a vertical orientation
Y axis overtravel Not applicable Hinged breakout from base
55 mm travel at port height
Z axis overtravel Not applicable Hinged docking port assembly
90° travel in –Z axis
Inhibit range Not applicable Not applicable
