f) History mode
Inthismode,youcanhavetheindividualsaveddatarecordsdisplayedthatthebasisstationlesinits internal
memory due to the set measuring interval. The basis station offers a total of 3552 memory slots.
• Thebasisstationmustbeinnormalmode.Nowbrieypushthe"HISTORY"(7)buttontostartthehistorymode.
 Toleavethehistorymodeinanyplace,brieypushthebutton"HISTORY"(7).
Alternatively, wait for 30 seconds without pushing a button. History mode is ended automatically in this
case.
• Thebottom-mostdisplaylineshows"HISTORYNONERECORD"whennodataarepresentyet(e.g.atrstcom-
missioning or after reading and deleting the data via a PC).
If there are data records, e.g. the display "HISTORY P/R 15.08" and "YEAR/SECOND 15.33" appears.
P 15 = memory base 15 (each memory base has 32 data records)
R 08 = data record 08
YEAR 15 = year 2015
SECOND 33 = second 33
The time that belongs to the data record (hour/minute) and the date (time/month) of the data record is displayed at
the upper left in the display.
This way, you can determine precisely when the data record has been saved.
• You can use the "
" (3) or " " (4) button to switch to the previous/next memory base ("P"), if present. Keep the
respective button pressed for quick adjustment.
• You can use the "
" (1) or " " (2) button to switch to the previous/next data record ("R"), if present. Keep the
respective button pressed for quick adjustment.
• To delete the data records in the basis station, the basis station must be in history mode. Keep the "SET" button (5)
pushed for at least 2 seconds then. "CLEAR RECORD" will appear at the bottom of the display. After 2 seconds,
all present data will be deleted.
If the memory is full, the respective oldest records are overwritten.
