12
HOW TO USE THE KEYPAD
The control panel of the S8 COMPACT includes an LCD screen and keypad for
navigating through the menus and delivering treatment.
LCD SCREEN
The LCD screen displays the menus and treatment screens.
KEYPAD KEYS
The S8 COMPACT keypad has the following keys:
LCD screen
Left key
Up key
Right key
Start/Stop key
Down key
Key Function
Start/Stop
• Starts or stops treatment.
Up
• Allows you to increase settings options and scroll through
the
S8 COMPACT menu.
Down
• Allows you to decrease settings options and scroll through
the
S8 COMPACT menu.
Left
• Performs the function indicated by the guiding text displayed
above it on the LCD screen. Guiding text includes menu,
change, and apply.
Right
• Performs the function indicated by the guiding text displayed
above it on the LCD screen. Guiding text includes exit and
cancel.
338249r1.book Page 12 Friday, June 10, 2005 3:22 PM
