Resol DeltaSol BS User Manual

DeltaSol
®
BS
© RESOL 04272 deltasol_bs.mon.pmd
| 10
4. Controller parameter and indication channels
4.1 Channel-overview
Arr specification page
channel
1 2*
COL x x Temperature collector 1 11
TST x Temperature store 1 11
TSTL x Temperature store 1 below 11
TSTU x
Temperature store 1 above
11
S3 x
Temperature sensor 3
11
TRF
c c
Temperature return sensor 11
S4
d d
Temperature sensor 4 11
n % x Pump speed relay 1 11
n1 % x Pump speed relay 1 11
h P x Operating hours relay 1 11
h P1 x Operating hours relay 1 11
h P2 x Operating hours relay 2 11
kWh
c c
Heat quantity kWh 12
MWh
c c
Heat quantity MWh 12
Arr 1-2 System 9
DT O x x Switch-on temperature difference 13
DT F x x Switch-off temperature difference 13
DT S x x Nominal temperature difference 13
RIS x x Increase 13
S MX x x Maximum temperature store 1 13
EM x x emergency temperature collector 1 14
Legend:
x
Corresponding channel is available.
x*
Corresponding channel is available if the appropriate option
is activated.
c
Corresponding channel is only available if the option heat
quantity measurement is activated (OWMZ).
MEDT
The channel antifreeze content (MED%) is only shown if a
medium other than water or Tyfocor LS / G-LS (MEDT
0 or 3) is used. The adjustment is only appropriate when
using other types of antifreeze.
d
Corresponding channel is only available if the option heat
quantity measurement is deactivated (OWMZ).
Please note:
S3 and S4 are only indicated in case of sensors connected.
* System 2 apply only for the version 68.30 and 69.30
Only by PG 67.30 and 69.30
Arr specification page
channel
1 2*
OCX x x option collector cooling collector 1 14
CMX x* x* maximum temperature collector 1 14
OCN x x option minimum limitation collector 1 14
CMN x* x* minimun temperature collector 1 14
OCF x x option antifreeze collector 1 14
CFR x* x* antifreeze temperature collector 1 14
OREC x x option reccoling 15
O TC x x option tube collector 15
AH O x switch-on temp. for thermostat 1 15
AH F x switch-off temp. for thermostat 1 15
OHQM x x option WMZ 12
FMAX
c c
maximum flow 12
MEDT
c c
antifreeze type 12
MED% MEDT MEDT antifreeze content 12
nMN x
minimum pump speed relay 1
16
n1MN x
minimum pump speed relay 1
16
HND x x
manual operation relay 1
16
HND2 x x
manual operation relay 2
16
LANG x x language 16
PROG XX.XX
program number
VERS X.XX
version number

Resol DeltaSol BS Specifications

General

Type	Solar Thermal Controller
Number of Inputs	4
Number of Outputs	2
Outputs	2 relay outputs
Enclosure Protection	IP20
Temperature Sensor Inputs	4 (Pt1000)
Mounting	Wall-mounted
Power Supply	220 … 240 V~
