Resol DeltaSol Plus User Manual

RESOL - Elektronische Regelungen GmbH • Heiskampstr. 10 • D-45527 Hattingen • Tel.:+49 (0) 23 24/96 48-0 • Fax: +49 (0) 23 24/96 48-55
eMail: technik@resol.de • Internet: http://www.resol.de
page 11/20
RESOL DeltaSol Plus
Universal temperature differential regulator with
integrated calorimeter
Mounting instructions
4.7. Menu overview
Main menu
Measurin
g
val
Reports
Balance val.
Adj. values
Options
Measuring
values
Tkol XXX.X°C
Tspu XXX.X°C
S3 (Tvorl) XXX.X°C
S4 (Trückl) XXX.X°C
S5 XXX.X°C
Volume XX.X l/h
Pump speed 1
XXX %
Pump speed 2
XXX %
Time XX:XX
back
Balance
values
Kolmax XXX.XX °C
Spmax XXX.XX °C
S3max XXX.XX °C
S4max XXX.XX°C
S5max XXX.XX °C
Heat XXX Wh
Heat XXX kWh
Heat XXX MWh
Pump XXXX h
Operating days XXXX d
back
Options
Tube col. X
Col-cooling X
Recooling X
Frost
protection
X
WMZ
X
Minimal X
Ext.-heat
exchanger
X
∆T R2
X
After-heating
X
Valve
X
back
Adjustment
values
Tspmax XX.X °C
∆
Ton
XX.X K
∆
Toff
XX.X K
∆T2on
XX.X K
∆
T2off
XX.X K
T-Thon XX.X°C
T-Thoff XX.X°C
t-Thon XX:XX
t-Thoff XX:XX
Tkolmax XXX°C
Tkolnot XXX°C
Tkolmin XX.X°C
Flowmeter XX.X l/min
Vol. Imp XX l/Imp
Frost
protection
XX Vol%
Min.-pump
speed
XXX %
Time XX:XX
back
Reports
Sensor cable
open
Sensor cable
short-circuit
non return
valve
∆
T to high
EEPROM
RTC
back
Note:
The selectable adjustment values
and options depend on different
versions and only appear in the
display if the display is not locked
by a chosen adjustment or by the
version.

Resol DeltaSol Plus Specifications

General

Number of relay outputs	3
Controller Type	Solar thermal controller
Application	Solar thermal systems
Functions	heat quantity measurement
Inputs	Pt1000
Outputs	3 relay outputs
Operating temperature	0 °C to 40 °C
