page 15/20
RESOL DeltaSol Plus
Universal temperature differential regulator with
integrated calorimeter
Mounting instructions
6.3. Solar system with 1 collector, 1 store, bybass and activated heat measurement:
Menu item facto ry se tting selected adjustm ent
Options
/ T ube co l.
N
Options / C o l. co o ling Y
Options
/ Recoo ling
N
Options / Frost protection N
Options
/ W M Z
NY
Options / M inim al
N
O
p
tions
/ Ext. heat exchan
g
.
NY
Options
/
∆
T R2
N
Options
/ After-heating
N
Options / V alve N Y
A djusted values / Tspm ax 60°C
Adjusted values
/
∆
Ton
5.0 K
Adjusted values /
∆
Toff
3.0 K
Adjusted values /
∆
T2on
5.0 K
Adjusted values /
∆
T2off
3.0 K
Adjusted values
/ T colm ax 120°C
Adjusted values / T co lsec
125°C
Adjusted values / flow m . 1 l/m in see flo wm eter
Ad
j
usted values/Frost
p
rot.
45 Vol%
A djusted values
/ M in.
pump speed
30 %
Adjusted values
/ T im e
current tim e
The regulator determines the temperature
difference between the collector sensor S1
and the store sensor S2. As soon as the
difference is higher than or identical to the
adjusted value of the switch-on temperature
difference (DTon), the pump (R1) is
activated, the primary circuit is heated. At
the same time the temperature difference
between S4 and S2 is determinated in
comparison with the second adjusted
temperature difference (DT2on). If this
temperature difference is higher than the
adjusted value, the valve is switched by relay
2 (R2), the store is loaded. By means of the
feed and return flow temperature sensors S4
and S5 and the flow measured by the
flowmeter and adjusted in the menu
Adjusted Values, the quantity of heat is
calculated.
The temperature sensor S3 is an additional
measuring sensor, that e.g. can measure the
temperature of the upper part of the store.
S1
S2
R1
S4
R2
S5
S3
Method of regulating
the flow:
1. Set the mode switch
in position ON
2. Regulate resp. check
the flow by means of the
flowmeter
3. Adjust the value in
Adjusted Values/Flow
