RESOL DeltaSol Plus
Universal temperature differential regulator with
integrated calorimeter
Mounting instructions
4. Menu structure
4.1. Main menu
In the main menu 5 submenus are available:
Measured values: indication of actual sensor
temperatures, relays status and time
Messages: messsages of errors, software version
Balance values:time, temperature and quantity of heat for
regulator and installation
Adjustments: adjustment of installation parameters resp.
regulation default
Options: activation or desactivation of options
Indictation:
The adjustments and options that can be chosen are
dependent on combinations and versions, they only appear
on the display if they are not blocked by one of the chosen
values (e.g. when the DT2-function is chosen, the option
WMZ can not be activated). To return from the submenu
to the main menu only BACK has to be selected at the end
of each menu. You will find a menu structogram on page
11.
4.3. Reports
In case of an error this is automatically displayed. Please see
the menu reports for a more detailed explanation:
Line break: interruption of the sensor lead
Short circuit: short-circuit in the sensor lead
Gravitation breaks: error in the gravitation breaks
DT to high: eventual error in the pumping
EEPROM: error during the storing
RTC: error in the real time
The measured values menu offers the possibility to display
the actual sensor temperatures for S1 to S5 (depending on
the version), the relative on-period (relative pump speed) for
relays 1 and 2 and the indication of adjustment of time:
Tcol (S1): present temperature of sensor 1 in °C
Tspu (S2): present temperature of sensor 2 in °C
S3: present temperature of sensor 3 in °C
(indication Tvorl in version V40)
S4: (only version flowmeter and V40)
present temperature of sensor 4 in °C
(indication Trückl in version V40)
S5: (only version flowmeter)
Vol um e: actual flow in l/h
Relay1: present relative switch-on duration for
relay 1 in %
Relay2: (only version flowmeter)
present relative switch-on duration for
relay 2 in %
Time: indication and adjustment of the actual
time
4.2. Measured values
Colmax: highest temperature measured at the
collector sensor
Stmax: highest temperature measured at the store
S3max: highest temperature measured at tem-
perature sensor S3 (indication Tvorlmax in
version V40)
S4max: (only version flowmeter and V40)
highest temperature measured at tem-
perature sensor S4 (indication Trückmax in
version V40)
S5max: (only version flowmeter)
highest temperature measured at tem-
perature sensor S5
Heat: quantity of heat in Wh, KWh or MWh
measured by the option WMZ
Pumpe: operating hours of the solar pump
Betr.tage: number of operating days of the regulator
4.4. Balance values

Resol DeltaSol Plus Specifications

General

Number of relay outputs	3
Controller Type	Solar thermal controller
Application	Solar thermal systems
Functions	heat quantity measurement
Inputs	Pt1000
Outputs	3 relay outputs
Operating temperature	0 °C to 40 °C
