Chapter 7: Repair & Replacement
Tranquility Quest Plus CPAP System Service Manual
22
1003740
(Figure 2)
Top Enclosure
Fuse Drawer
Bottom Enclosure
On / Off Switch
Ramp Buttom
Outlet Port
(Figure 1)
Fiber Optic
Communication Port
7.5 Repair Identification Photo’s
Replacement Filter
AC Inlet
Power Fuse Label
(Not Shown)
Front Overlay
