Appendix A: Tools and Equipment
Tranquility Quest Plus CPAP System Service Manual 32
1003740
Appendix A: Tools and Equipment
A.1Service Tools and Supplies
You should have the following hand tools and supplies available for
troubleshooting, testing, and repairing the Tranquility Quest Plus
CPAP System.
• Common Hand Tools
Flat-blade screwdriver - small
Phillips screwdriver - medium
• Antistatic, Electro-Static Discharge (ESD)-protected
work station – minimum requirement is a grounded
mat and wrist strap
• Digital Manometer – see Section A.2
• Digital Multimeter – see Section A.2
•O
2
Enrichment Port (RI P/N 312010)
• Test Orifice (RI P/N 532232)
• Whisper Swivel II (RI P/N 332113)
• Cleaning cloth
• Isopropyl alcohol
A.2Acceptable Test Equipment
A.2.1 Digital Manometer*
Specifications:
0 – 25 cm H
2
O (or better)
±0.3 cm H
2
O accuracy
±0.1 cm H
2
O resolution
Acceptable Options:
• Respironics Digital Manometer
(RI P/N 302227)
• Merical DP2001
• Sensym PDM 200CD
• RT-200
• Any commercially available digital
manometer that meets the above specifica-
tions.
* A water-column manometer may also be used.
• Mild detergent
