Retevis RT95 User Manual

3
RT95 UHF/VHF Two Way Radio
3. INITIAL INSTALLATION
To install the transceiver, select a safe, convenient location inside your vehicle that
minimizes danger to your passengers and yourself while the vehicle is in motion. Consider
installing the unit at an appropriate position so that knees or legs will not strike it during
sudden braking of your vehicle. Try to pick a well ventilated location that is shielded from
direct sunlight.
1.Install the mounting bracket in the vehicle using the supplied selftapping screws (2pcs)
and at washers (2pcs)
2.Position the transceiver, then insert and tighten the supplied hexagon SEMS screws.
♦ Double check that all screws are tightened to prevent vehicle vibration from loosening
the bracket or transceiver.
Car body
Washer (M5)
Tapping screw
(M5x20mm)
Mounting bracket
3.1 Mobile Installation
3.2 DC Power Cable Connection
»
Locate the power input connector as close to the transceiver as possible.
3.2.1 Mobile Operation
The vehicle battery must have a nominal rating of 12V. Never connect the transceiver to
a 24V battery. Be sure to use a 12V vehicle battery that has sufcient current capacity. If
the current to the transceiver is insufcient, the display may darken during transmission,
or transmitting output power may drop excessively.

Retevis RT95 Specifications

General

Channels	200
Frequency Stability	±2.5ppm
Frequency Range	VHF:136-174MHz
Voltage	13.8V DC ±15%
Channel Spacing	25kHz/12.5kHz
Operating Temperature	-20°C to +60°C
