Retsch GM200 - Device Component Overview; Parts List and Functional Descriptions

Operating the machine
18
Pos: 8.6 /00005 Üb erschriften/1.1 Ü berschriften/ 1.1 Überschrifte n BDA/11 Übersic htstabelle d er Geräteteile @ 0\ mod_122 8990616846_9. doc @ 4972 @ @ 1
5.2 Overview table of the parts of the device
Pos: 8.7 /00010 B edienungsanlei tungen Kapitelsa mmlungen/GM 200 (2010)/0 015 GM200N Bedienung/1505 GM200_2010 Mo dul Tabelle d er Geräteteile @ 3\mod_1279 721225379_9.d oc @ 21541 @ @ 1
Element
Description
Function
A
Jar lid
Seals the grinding jar
B
Knife cylinder
Cuts and grinds the sample material
C
Grinding jar
Holds the sample material
D
Jar holder
Holder for the grinding jar
E
Operating panel with displays
Start / stop / program memory and displays
F
Grinding chamber hood
Protective hood for safe grinding operations
G
Pin for knife cylinder
Drive shaft for knife cylinder
H
Support for grinding jar
Centres the grinding jar and the jar holder
J
Grinding chamber hood interlock
Locks the grinding chamber hood into place
K
Thermal fuse
Protective switch against overheating
L1
On/off switch
Separates the machine completely from the mains
L3
Socket for non-heating apparatus
Connection for mains cable
M
Vent
Ventilation of motor and inside chamber
O
O ring
Fixes the grinding chamber holder
