Operating the machine
25
NOTE
The gravitation lids for the plastic jug differ from the gravitation lids for the glass
and steel grinding jugs.
Pos: 8.37 /00005 Ü berschriften/ 1.1 Überschrifte n/1.1 Überschrift en BDA/11 Füll en des Behält ers @ 2\mod _126777486855 6_9.doc @ 1887 0 @ 2 @ 1
5.10 Filling the vessel
Pos: 8.38 /00004 Warnhinweis e/V0039 VORSICHT Schnittverle tzung Scharfe M esserklinge (GM 200_2010) @ 3\ mod_128 2898421988_9. doc @ 22916 @ @ 1
CAUTION
2.V0039
Danger of injuries caused by cuts
Sharp cutters
– The cutters are very sharp and may lead to injuries caused by cuts if
handled incorrectly.
• Do not directly take hold of the cutters.
• Only reach into the grinding jar if it is outside the device.
• Do not reach into the grinding jar if the sample material still covers
the cutter.
• Before taking out the cutter remove as much sample material to
safely grip the cutter.
Pos: 8.39 /00004 Warnhinweis e/H0054 HINW EIS Haube muss sic her in den V erriegelungsbolz en einrasten @ 3\mod_1283 176291349_9.d oc @ 22962 @ @ 1
NOTE
3.H0054
The hood must safely latch into the interlock pin so that the motor can start or so
that no emergency brake is triggered during grinding.
Insert the cutter cylinder before adding the sample material because otherwise it
may fall between cutter cylinder and jug.
Pos: 8.40 /00005 Ü berschriften/ 1.1.1 Überschrift en/111 Füllen – innerhalb des Gerätes @ 3\ mod_12797168 76335_9.doc @ 21485 @ @ 1
5.10.1 Filling – within the device
Pos: 8.41 /00010 Bedienungsa nleitungen Kapitels ammlungen/GM 200 (2010)/ 0015 GM200N B edienung/15 60 GM200_20 10 Modul Füllen in nerhalb @ 3\ mod_1279721 707174_9.doc @ 21631 @ @ 1
• Insert the jug.
• Position the cutter cylinder and push it down as far as it will go.
• Add the sample material.
• Put on the lid.
• Close the hood until it latches into the interlock pin (J).
