Retsch ZM 200 - Operation Using the Display Unit of the ZM200

01.12.2016  Retsch GmbH 17
Operation using the display unit of the ZM200
D F
A
B
C
Name
Function
A
Display
Displays the menu, the parameter settings, operating information and error
messages.
B
START button
Starts the grinding process
C
STOP button
Stops the grinding process
D
Button
Opens the grinding chamber cover
F
Control knob
All menu items can be selected and parameters set by twisting and pressing
the knob.
