Display unit – operation of the device
This device offers a new, user-friendly user interface. All relevant data can
be entered and retrieved using a graphics display with one-button
operation. The menu navigation is available in different languages.
Adjustment options using the display menu
The selection bar in the display should be operated as follows:
Rotating function I)
• Rotate the operating button to get to the different menu items. The
selected menu items are marked using the dark selection bar. Areas
that cannot be changed are skipped.
Rotating function II)
• Rotate the operating button to change numerical values and decisions
in the menu items.
Press I)
• Press the operating button to open selected menu items.
Press II)
• Press the operating button to confirm settings.
Press III)
• Keeping the operating button pressed for longer takes you back to the
basic screen (Level 1).
Navigating between operating modes
• Rotate the operating button in a clockwise direction until the dark line
cursor is in the navigation menu (C1).
• Press the operating button (F).
– The icon for the scrolling direction (C4) changes from
• By rotating the operating button, navigate between manual operation
and the basic settings operating modes.
• Press the operating button (F) to activate the selected operating
mode.
– The icon for the scrolling direction (C4) changes from
• By rotating the operating button, switch to the sub-items of the
selected menu item.
Direct access to the language menu
If you have unintentionally set the wrong language , you can go straight to
the language menu by following the following steps.
