REVV GENERATOR - 3.0 Rear Panel Layout; 3.1 Main Power Connection; 3.2 Main & HT Fuses

Revv Owner’s Manual3.0
3.1
3.2
rear panel layout
Main Power Connection
When plugging the amplifier into the
mains A/C wall receptacle, always make
sure the amplifier power and standby
switches are in the off position. The
Required voltage and fuse ratings are
marked on the amplifier, verify that they
are correct before plugging it in.
Main & HT Fuses
The mains fuse and HT fuse are in place
to protect you and the amplifier from
overload conditions. Always replace
them with the same type and rating
only! Always unplug the amplifier from
the mains before replacing the fuses.
Fuse requirements are marked on the
rear panel of the amplifier.
MAINS
SE
HT
T1A
BIAS
GND
FAULT
T.5A
V1/V3
V1/V3V2/V4
T.5A
V2/V4
Model # PC1G100
Serial #
Made in Canada by
The Generator 100 Watt Amplifier
CAUTION: Never power on amp wihtout speakers connected!
FOOTSWITCHMIDI THRUMIDI IN
SPEAKERS
SPEAKER CABINET
LIGHTING
CAUTION: Setting incorrectly
cl r  mge!
IMPEDANCE
FX LOOP
LINE OUT
LEVEL
LEVEL
SEND RETURN
OUT
4
16
8
F
U
S
E
F
U
S
E
F
U
S
E
F
U
S
E
100V / T4A
120V / T4A
230V / T2A
240V / T2A
MAINS / FUSE
WARNING: To reduce the risk of a lethal electric shock,
do not remove chassis. Service should be performed by
qualied personnel only. No user serviceable parts inside.
Do Not Open!
CAUTION: Unplug power before moving fuses.
Replace with same type and rating only!
