Revv Owner’s Manual6.3
LED flashing, and as you increase in
number, MIDI channel 4 will be signified by
all three channel LEDS and the aggression
LED flashing, but once MIDI channel 5 is
selected, only the CH1 CLEAN LED will
flash again. Every time you reach MIDI
channel 5, 9, or 13, the LED cycle will once
again start from the CH1 CLEAN LED. So
keep count as you select the channel you
desire. If you go past MIDI channel 16, the
count will start at channel 1 again.
Once saved to memory, the Channel
LEDs will flash very quickly a number
of times to verify the change has been
made and completed. The amp will then
restart, completing the MIDI channel
change procedure.
6.4
6.5
MIDI Program Change
The Generator can remember up to 128
program settings of the MIDI controlla-
ble functions (See 6.5). In order to set a
program (AKA amplifier configuration)
to be controlled via MIDI:
1) Set the amplifier to the configuration
you intend to save to a program number.
(Ex: Ch: 2, Aggressive level: 2, Fat: ON,
Master Volume: 2, FX Loop: OFF, etc)
2) Once the Generator is configured as
you would like, press the store switch.
The Store LED will flash and the amplifi-
er will wait now for a command through
its MIDI IN jack.
3)
Send a program change command
from your MIDI Pedal or other equipment
with the correct channel and program
number you intend to have the Generator
save the current configuration to.
4) Once the command is received, the
Generator will save the current amp
configuration to that program number.
The Store LED will flash 3 times and
turn off verifying that the command has
been received and saved.
Now, anytime you send that program
number to the Generator from your
MIDI pedal or other external equipment,
the Generator will switch to that saved
configuration. This will allow for any con-
figuration of the Generators settings for
quick switching and a very versatile rig!
MIDI Controllable Functions
The Generator functions that can be
controlled via MIDI are as follows:
Channel Selection
3 Aggression Levels (Channel 2)
Bright function (Channel 2)
Fat function (Channel 2)
FX Loop in/out
Master Volume 1 and 2
Mute
These functions can be set and con-
trolled in a MIDI program change setting
(See 6.4), where one program change
command will call up a configuration
of the above settings, or continuous
controller commands (See 6.6), where
a CC command will switch any one of
the functions listed above, independent
from any of the others. The CC command
functions are great for things like instant
access buttons on foot pedals etc.
