8
Occasionally use a cloth to wipe off chips
and dust from the machine. And oil the
rotary parts once a month to extend the tool
life. Do not oil the motor.
Check the motor brushes after the rst
50 hours of use for a new machine or after
a new set of brushes have been installed.
After the rst check, examine them every
10 hours of use.
When the carbon is worn to 6 mm in length
or if the spring or shunt wire is burned
or damaged, replace both brushes. If
the brushes are found serviceable after
removing, reinstall them.
General Maintenance
Brush Inspection
WARNING! For your own safety, turn the
switch off and remove the plug from the
power source outlet before maintaining
or lubricating your miter saw.
Maintenance
INSTALLING THE BLADE
(FIG. 15, 16, 17)
Unplug the miter saw before changing/
installing the blade.
1. Install a 255 mm blade with a 25.4 mm
arbor hole with a 16 mm reducer making
sure the rotation arrow on the blade
matches the clockwise rotation arrow
on the upper guard, and the blade teeth
are pointing downward.
2. Place the blade (8), the reducer (7) and
the arbor collar (6) in turn on the motor
arbor. Thread the arbor bolt (4) onto
the motor arbor in a counterclockwise
direction. (Fig. 17)
IMPORTANT: Make sure the at of the
blade collar is engaged with the at on
the arbor shaft.
3. Place the blade wrench on the arbor
bolt (4).
4. Press the arbor lock (5), holding
it in rmly while turning the blade
counterclockwise. When arbor lock (5)
engages, continue to press it in while
tightening the arbor bolt securely.
(Fig. 16)
5. Rotate the cover plate (3) back to its
original position until the slot in the
cover plate engages with the cover
plate screw (2). While holding the lower
blade guard (1), tighten the cover plate
screw (2) with a Phillips screwdriver.
(Fig. 15)
