14
I.D. Description Size Q'ty
0HX9 NEEDLE BEARING 1
0JCD SPRING PIN 1
0JX7 HEX. SOC. SET SCREW M6*1.0-6 2
0K43 CR. RE. PAN HD. SCREW & WASHER M5*0.8-16 2
0K44 CR. RE. PAN HD. SCREW & WASHER M5*0.8-12 1
0QGR COMPRESSION SPRING 1
0QQU CARBON BRUSH ASS'Y 2
0QR0 BRUSH COVER 2
1468 CR. RE. PAN HEAD TAPPING & WASHER SCREW M5*12-70 2
2DED SLOTTED SET SCREW M6*1.0-6 2
2DW9 WAVE WASHER BWW-608 1
2VGY GEAR BOX 1
2VPU FLOW GUIDE 1
2ZS3 BRUSH HOLDER ASS'Y 2
3236 CR. RE. PAN HD. SCREW & WASHER M6*1.0-55 4
32C5 BRACKET STOP ASS'Y 1
32GU CUTTER SHAFT ASS'Y 1
3738 FIELD ASS'Y 1
3739 ARMATURE ASS'Y 1
373D MOTOR COVER 1
ORDER ONLY BY MODEL NUMBER AND PART NUMBER
M2503R MOTOR PARTS LIST
