Input / Output terminal functions
Code Name Setting range Default
At-
trib.
b34 Stopping mode selection
0: OFF; 1: X1; 2: X2;
3: X3; 4: on
0 ●
b35 Jogging mode selection 0: OFF; 1: X1; 2: X2; 3: X3 0 ●
b45
Switching between local and remote
control
0: OFF; 1: X1; 2: X2; 3: X3 0 ●
E39 Self-holding function 0: OFF; 1: X1; 2: X2; 3: X3 0 ●
H07 DC braking holding options 0: OFF; 1: X1; 2: X2; 3: X3; 4: ON 0
H23 Energy saving mode
0: Disabled; 1: X1; 2: X2; 3: X3; 4:
Automatic energy saving
0 ●
H28 Process PI deactivation 0: OFF; 1: X1; 2: X2; 3: X3 0 ●
E04 FM1 selection 0...4 0
E05 FM1 gain setting 0.50...9.99 1.00
E06 FM2 selection 0...4 1
E07 FM2 gain setting 0.50...9.99 1.00
E08 FM channel mode 0...3 0
E09 Pulse output selection 0...3 2
E10 Maximum output pulse frequency 0.1...50.0 kHz 10.0 kHz
E11 Frequency level detection FDT1 0.00...599.00 Hz 50.00 Hz
E12 FDT1 lagging frequency 0.00...599.00 Hz 1.00 Hz
E13 Frequency level detection FDT2 0.00...599.00 Hz 25.00 Hz
E14 FDT2 lagging frequency 0.00...599.00 Hz 1.00 Hz
E15 Frequency arrival detection range 0.00...599.00 Hz 2.00 Hz
E16 Open collector output OUT1
0...25
6
E17 Open collector output OUT2 0
E18 Relay Ry output selection 12
E04, E06 setting range：
0: Output frequency
1: Output voltage
2: Output current
3: PI feedback signal
4: Set frequency
E08 setting range:
0: FM1 outputs 0...20 mA or 0...10 V, FM2 outputs 0...20 mA or 0...10 V
