Risk of destroying the touch screen or the front
panel by using inappropriate items.
NOTICE
Operate the touch screen only with your finger or with a special touch pen
(parts number 1070923266).
5 Spare Parts, Accessories and Wear Parts
5.1 Y-Repeater
Connecting unit to connect two operator displays featuring the same resolution
and the same version to one control cabinet PC.
Ordering code Part number Description
VAC01.1S-YD1-NNNN R911171187 Y-repeater for CDI interface
Tab. 5-1: Y-Repeater
5.2 External 24 V Power Supply Unit
Ordering code Part number Description
VAP01.1H-W23-024-010-NN R911171065 External 24 V power supply unit for the
IndraControl V devices
Tab. 5-2: External 24 V power supply unit for the operator display
5.3 Uninterruptible Power Supply (UPS)
Ordering code Part number Description
VAU01.1U-024-024-240-NN R911171024 Uninterruptible power supply
DC 24 V, 240 watts with USB interface
Tab. 5-3: Uninterruptible power supply (UPS)
5.4 Connecting Cables for the CDI Interface
Malfunctions caused by using inappropriate CDI cables.
Use only cables listed in the following overview.
Ordering code Part number Description
RKB0008/000,5 (*******-*******-*******) R911171484 Length 0.5 m
RKB0008/001,0 (*******-*******-*******) R911171485 Length 1 m
RKB0008/002,5 (*******-*******-*******) R911170151 Length 2.5 m
RKB0008/005,0 (*******-*******-*******) R911170152 Length: 5 m
Bosch Rexroth AG
Spare Parts, Accessories and Wear Parts
VDP 16.3, VDP 40.3, VDP 60.3
6/53
DOK-SUPPL*-VDP*XX.3***-IT03-EN-P
