REXROTH IndraControl VDP 16.3 User Manual

In operation Transport Storage
Mechanical strength Max. vibration:
Frequency range: 10 Hz
to 150 Hz
Excursion: 0.075 mm at
10 Hz to 57 Hz
Acceleration: 1 g at
57 Hz to 150 Hz
acc. to EN 600068-2-6
Max. shock:
15 g 11 ms
acc. to EN 60068-2-27,
no disturbance of the
function
Max. shock:
15 g 11 ms
acc. to EN 60068-2-27,
no disturbance of the
function
Contamination level 2
Overvoltage category 2 -
Tab. 6-1: Ambient conditions
7
Technical Data
VDP 16.3DB VDP 16.3AK VDP 16.3BK
Display 305 mm TFT (12"), 800 x 600 pixels, 16.7 million colors
Operation Touch screen operation Key operation
Surface − front panel Color RAL 7035
Light gray
Graphite gray
(Bosch design)
Color RAL 7035
Light gray
Enclosure rating Front panel IP 65 according to DIN EN 60 529
Front type 1 according to NEMA (UL)
Rear panel IP 20
Interface on the front
panel
USB connection,
Cover degree of protec-
tion IP 65
No USB USB connection,
Cover degree of protec-
tion IP 65
Voltage supply DC 24 V (use a 24 V power supply unit according to DIN EN 60742, classifi-
cation VDE 0551, for example the power supply unit VAP01.1H-
W23-024-010-NN, part number R911171065)
Current consumption 0.85 A
Power loss 20 W
USB Per USB port max. 500 mA, total current at all USB ports is max. 1 A
Weight 4.0 kg
Tab. 7-1: Technical data of the VDP 16.3
VDP 16.3, VDP 40.3, VDP 60.3 Bosch Rexroth AG
Technical Data
DOK-SUPPL*-VDP*XX.3***-IT03-EN-P
9/53
