12.2.2 VDP 16.3 Keys and VDP 40.3 Keys
Function and operating keys (F... + OP...)
The assignment of the function and operating keys (F... + OP...) is determined
by the respective application software.
OP-Keys
The following key codes are transmitted to the operating system:
Key at the VDP 16.3, VDP 40.3 Key code
OP2
to
OP9
<CTRL> + <SHIFT> + <ALT> + <F2>
<CTRL> + <SHIFT> + <ALT> + <F9>
Prog <CTRL> + <SHIFT> + <ALT> + <Q>
INFO <CTRL> + <SHIFT> + <ALT> + <I>
Tab. 12-1: Key code for the VDP 16.3 and VDP 40.3
M-Keys
Eight M-keys (machine function keys) are positioned to the right and to the left
of the display. The keys on the right side of the display are labeled with R1 to
R8, the keys on the left side of the display with L1 to L8.
Addressing of the M-keys
The state of the M-keys can be read out in different ways:
● Pressed M-keys are transmitted as USB keyboard signals to the PC
● The M-keys are transferred bit-coded to the control cabinet PC via the serial
connection of the CDI interface. There, they can be output via a Profibus-DP
slave card. They are also provided at a connector strip to pass on the signals
to the corresponding extension card. The transmission protocol is ensured by
means of the hardware. If there are interferences or if the connection is inter-
rupted, the incoming M-key bits are disabled after 10 ms
Requesting M-keys via Windows applications
The following key codes are transmitted to the operating system:
VDP 16.3, VDP 40.3, VDP 60.3
Bosch Rexroth AG
Device Description
DOK-SUPPL*-VDP*XX.3***-IT03-EN-P
39/53
