REXROTH IndraControl VDP 16.3 User Manual

VDP 40.3DI VDP 40.3AL
USB Per USB port max. 500 mA, total current at all USB ports is max. 1 A
Weight 5.8 kg
Tab. 7-3: Technical data of the VDP 40.3 (DI, AL)
VDP 60.3FE
Display 483 mm TFT (19"), 1280 x 1024 pixels, 16.7 million colors
Operation Touch screen operation
Surface − front panel Color RAL 7035, light gray
Enclosure rating Front panel IP 65 according to DIN EN 60 529
Front type 1 according to NEMA (UL)
Rear panel IP 20
Interface on the front
panel
USB connection (front panel)
Cover degree of protection IP 65
Voltage supply DC 24 V (use a 24 V power supply unit according to DIN EN 60742, classifi-
cation VDE 0551, for example the power supply unit VAP01.1H-
W23-024-010-NN, part number R911171065)
Current consumption 1.7 A
Power loss 40 W
USB Per USB port max. 500 mA, total current at all USB ports is max. 1 A
Weight 7.3 kg
Tab. 7-4: Technical data of the VDP 60.3
8
Standards
8.1 Used Standards
Standard Meaning
EN 60,204 -1 Safety of machinery - Electrical equipment of machines
EN 61,000-6-4 Generic standards - emission standard (industrial environments)
EN 61,000-6-2 Generic standards – noise immunity (industrial environments)
EN 61,558-2-6 Transformer for 24 V power supply unit, protective separation
EN 60,664 -1 Overvoltage category II
EN 61,131 -2 24 V outputs requirements
EN 61,131 -2 24 V current supply requirements
ISO 13,850 Safety of machinery, EMERGENCY STOP devices
EN 60 529 Degrees of protection (including housings and installation com-
partments)
VDP 16.3, VDP 40.3, VDP 60.3 Bosch Rexroth AG
Standards
DOK-SUPPL*-VDP*XX.3***-IT03-EN-P
11/53
