VDP 40.3DE VDP 40.3BI VDP 40.3DF
Display 381 mm TFT (15"), 1024 x 768 pixels, 16.7 million colors
Surface front panel Color RAL 7035
Light gray
Operation Touch screen operation Key operation Touch screen and key
operation
Enclosure rating Front panel IP 65 according to DIN EN 60 529
Front type 1 according to NEMA (UL)
Rear panel IP 20
Interface on the front
panel
USB port, cover, degree of protection IP 65
Voltage supply DC 24 V (use a 24 V power supply unit according to DIN EN 60742, classifi-
cation VDE 0551, for example the power supply unit VAP01.1H-
W23-024-010-NN, part number R911171065)
Current consumption 1.05 A
Power loss 25 W
USB Per USB port max. 500 mA, total current at all USB ports is max. 1 A
Weight 5.8 kg
Tab. 7-2: Technical data of the VDP 40.3 (DE, BI, DF)
VDP 40.3DI VDP 40.3AL
Display 381 mm TFT (15"), 1024 x 768 pixels, 16.7 million colors
Surface front panel Color RAL 7035
Light gray
Graphite gray
Bosch Design
Operation Touch screen operation and switch-
ing elements
Touch screen operation
Enclosure rating Front panel IP 65 according to DIN EN 60 529
Front type 1 according to NEMA (UL)
Rear panel IP 20
Interface on the front
panel
USB port, cover, degree of protec-
tion IP 65
No USB
Voltage supply DC 24 V (use a 24 V power supply unit according to DIN EN 60742, classifi-
cation VDE 0551, for example the power supply unit VAP01.1H-
W23-024-010-NN, part number R911171065)
Current consumption 1.05 A
Power loss 25 W
Bosch Rexroth AG
Technical Data
VDP 16.3, VDP 40.3, VDP 60.3
10/53
DOK-SUPPL*-VDP*XX.3***-IT03-EN-P
