REXROTH IndraControl VDP 16.3 User Manual

Ordering code Part number Description
RKB0008/010,0 (*******-*******-*******) R911170153 Length 10 m
RKB0008/015,0 (*******-*******-*******) R911171183 Length 15 m
RKB0008/020,0 (*******-*******-*******) R911171184 Length 20 m
RKB0008/025,0 (*******-*******-*******) R911170154 Length 25 m
RKB0008/030,0 (*******-*******-*******) R911171381 Length 30 m
RKB0008/035,0 (*******-*******-*******) R911171369 Length 35 m
RKB0008/040,0 (*******-*******-*******) R911171382 Length 40 m
RKB0008/050,0 (*******-*******-*******) R911171383 Length 50 m
Tab. 5-4: Connecting cables to control cabinet PC, panel PC and operator display
Further cable lengths are available on request.
Two cables are always required to establish a connection between
the VxB and the VDP.
5.5 Connecting Cables for the USB Interface
Ordering code Part number Description
RKB0019/000,5 (*******-*******-*******) R911171165 USB connecting cable,
Length 0.5 m
RKB0019/001,0 (*******-*******-*******) R911171166 USB connecting cable,
Length 1 m
RKB0019/003,0 (*******-*******-*******) R911171167 USB connecting cable,
Length 3 m
RKB0019/005,0 (*******-*******-*******) R911171168 USB connecting cable,
Length 5 m
Tab. 5-5: Connecting cables to the control cabinet PC
5.6 USB Cables with Increased Noise Immunity
If the UPS is used in noisy environment, mal-
functions are possible.
NOTICE
Use only USB cables with high noise immunity for the connection between con-
trol cabinet PC and uninterruptible power supply (VAU 01.1 U) with communica-
tion interface.
VDP 16.3, VDP 40.3, VDP 60.3
Bosch Rexroth AG
Spare Parts, Accessories and Wear Parts
DOK-SUPPL*-VDP*XX.3***-IT03-EN-P
7/53
