When installing CDI cables with a diameter of 7.4 mm observe the
bending radius:
● Radius (when bended once during installation): 4 × cable diame-
ter
● Minimum bending radius (when moved permanently): 8 × cable
diameter
● Optimum bending radius (when moved permanently): 12.5 × ca-
ble diameter
Breakdown of the operation due to mechanical forces which impact
the CDI cables.
Avoid mechanical stress (tensile, compressive, torsional and lateral
forces) caused by connectors to the RJ45 female connector.
Breakdown of the operation due to changed CDI cables.
To be able to clearly identify the cables, label the cables, e.g. with a
cable marker or clips.
The maximum cable length depends on the display resolution:
● Up to 60 meters: 1280 × 1024 pixels (only VDP 60.3)
● Up to 70 meters: 1024 × 768 pixels (only VDP 40.3 and VDP 60.3)
● Up to 80 meters: 800 × 600 pixels (all VDPxx.3)
Longer cable lengths can be realized using the Y-Repeater (see chap-
ter 12.4 "Y-Repeater" on page 41).
Screen output interference due to VDP device exchange during run-
ning operation if the resolution of the exchanged device is different.
The display resolution is detected only once after switching on the
control cabinet PC. Consequently, if a VDP is plugged and then re-
moved or if a VDP is connected when starting the control cabinet
PC, only a VDP with the same resolution can be connected again.
Thus, it is ensured that the screen output on the connected and dis-
connected VDP is executed automatically without switching the
screen output to the VDP using the keyboard.
Malfunctions caused by using inappropriate cables.
Use only cables listed in chapter 5 "Spare Parts, Accessories and
Wear Parts" on page 6.
VDP 16.3, VDP 40.3, VDP 60.3 Bosch Rexroth AG
Assembly, Disassembly and Electrical Installation
DOK-SUPPL*-VDP*XX.3***-IT03-EN-P
35/53
