Reznor RCB User Manual

Form CP-MAPSIII-D21, Doc No 303070, Page 27
Quick Setpoints A8 Quick Setpoints Screen A8 (Cont’d)
Name Description Default Unit Min Max
NAHRDAMin:
Neutral Air Heat DA SP Reset DA Min - Sets the minimum neutral air heating discharge air
temp reset setpoint
65 Deg F 50 140
NAHROAMax:
Neutral Air Heat DA SP Reset OA Max - Sets the maximum neutral air heating outside air
temp reset setpoint
65 Deg F 0 100
NAHROAMin:
Neutral Air Heat DA SP Reset OA Min - Sets the minimum neutral air heating outside air
temp reset setpoint
30 Deg F 0 100
Quick Setpoints A9 Quick Setpoints Screen A9 Will Be displayed when the unit is congured for Dehumidication
Name Description Default Unit Min Max
DhOADP_SP:
SetstheDehumOADewPointSP-UsedtoallowNeutralAirDehumidicationModewhen
the OA dew point is greater than SP
58 Deg F 50 100
DhOADP_Diff: Dehum OA Dew Point SP Differential - Sets the differential for the DhOADP_SP 2 Deg F 05 10
Quick Setpoints A10 Quick Setpoints Screen A10 Will Be displayed when the unit is congured for Building Pressure Control
Name Description Default Unit Min Max
Pressure Control Factory Selection: Building
Controlled Device Factory Selection: Supply Fan - Exhaust Fan - Dampers
Bldg_Pressure Building Static Pressure
Setpoint: Building Static Pressure SP 0.1 iwc -0.5 0.5
Quick Setpoints A11 Quick Setpoints Screen A11 Will Be displayed when the unit is congured for Duct Pressure Control
Name Description Default Unit Min Max
Pressure Control Factory Selection: Duct
Controlled Device Factory Selection: Supply Fan
Duct_Pressure Duct Static Pressure
Setpoint: Duct Static Pressure SP 0.5 iwc 0 2.5
Main Menu
B Schedule Schedule Menu
Schedule B1 Schedule Screen B1
Name Description Default Unit Min Max
Date: Sets the current month day and year - Default Value: Factory Date
Hour: Sets the current time - Default Value: Factory Time
Schedule B2 Schedule Screen B2
Name Description Default Unit Min Max
DST: Set to enable DST - Default Value: Enable
Transition Time: Sets Transition Time - Default Value: 60 min
Start: Sets Start day , month and time - Default Value: Last Sunday in March at 2:00
End: Sets End day , month and time - Default Value: Last Sunday in October at 3:00
Schedule B3 Schedule Screen B3 will be displayed if unit OccMode_Sel is set to Schedule
Name Description Default Unit Min Max
Schedule #: ModiableFieldusedtoadvancethrough10availableWeeklySchedules
Time On: Sets the desired On time for selected Schedule #
Time Off: Sets the desired Off time for selected Schedule #
Days Enabled: Sets the desired days of the week for the selected Schedule #
Schedule B4 Schedule Screen B4 will be displayed if unit OccMode_Sel is set to Schedule
Name Description Default Unit Min Max
1: Sets the desired Holiday Range 1: For Extended Unoccupied Mode 0/0 - 0/0
2: Sets the desired Holiday Range 2: For Extended Unoccupied Mode 0/0 - 0/0
3: Sets the desired Holiday Range 3: For Extended Unoccupied Mode 0/0 - 0/0
4: Sets the desired Holiday Range 4: For Extended Unoccupied Mode 0/0 - 0/0
Schedule B5 Schedule Screen B5 will be displayed if unit OccMode_Sel is set to Schedule
Name Description Default Unit Min Max
5: Sets the desired Holiday Range 5: For Extended Unoccupied Mode 0/0 - 0/0
6: Sets the desired Holiday Range 6: For Extended Unoccupied Mode 0/0 - 0/0
7: Sets the desired Holiday Range 7: For Extended Unoccupied Mode 0/0 - 0/0
8: Sets the desired Holiday Range 8: For Extended Unoccupied Mode 0/0 - 0/0
