Integer Variables
Name Description R/W
BMS
Address
Unit Default Min Max
Bldg_Pressure* Building Static Pressure R AV1001 iwc
Bldg_Press_SP* Building Static Pressure SP R/W AV1002 iwc 100 -500 500
Duct_Press_SP* Duct Static Pressure SP R/W AV1003 iwc 500 0 2500
Spc_Hum Space Humidity R AV1004 %rH
SpcHumSP Space Humidity SP R/W AV1005 %rH 55 35 75
State_Sel State Select 2=AUTO 3=COOL 4=HEAT 5=OFF R/W AV1006 5 2 5
OccMode_Sel Occ Mode Select 0= Schedule 1= Digital Input 2= BMS R/W AV1007 1 0 2
Spc_CO2 Space CO2 R AV1008 ppm
SpcCO2SP Space CO2 SP R/W AV1009 ppm 1,000 0 2,000
Duct_Pressure* Duct Static Pressure R AV1010 iwc
*Note: Divideby1000withthesupervisorysystemtoreecttheappropriatedecimalprecision.
Digital Variables
Name Description R/W
BMS
Address
Unit Default Min Max
Alm_Rly_Cmd Unit General Alarm Relay Command R BV1 Off On
Comp_Stg1_Cmd Compressor Stage 1 Command R BV2 Off On
Comp_Stg2_Cmd Compressor Stage 2 Command R BV3 Off On
Comp_Stg3_Cmd Compressor Stage 3 Command R BV4 Off On
Comp_Stg4_Cmd Compressor Stage 4 Command R BV5 Off On
Ext_OCC Occupied Mode Input R BV6 Off On
Ext_Switch_1 External Damper Position Sw 1 R BV7 Off On
Ext_Switch_2 External Damper Position Sw 2 R BV8 Off On
HX_Stg1_Cmd Heating Stage 1 Command R BV9 Off On
HX_Stg2_Cmd Heating Stage 2 Command R BV10 Off On
HX_Stg3_Cmd Heating Stage 3 Command R BV11 Off On
HX_Stg4_Cmd Heating Stage 4 Command R BV12 Off On
HX_Stg5_Cmd Heating Stage 5 Command R BV13 Off On
HX_Stg6_Cmd Heating Stage 6 Command R BV14 Off On
NA_Clg_Md Neutral Air Cooling Mode R BV15 Off On
NA_Dehum_Md Neutral Air Dehum Mode R BV16 Off On
NA_Htg_Md Neutral Air Heating Mode R BV17 Off On
OA_Hum_Sel Share OA Humidity from BMS (0=Probe 1=BMS) R/W BV18 Off Off On
OA_Temp_Sel Share OA Temp from BMS (0=Probe 1=BMS) R/W BV19 Off Off On
Phase_Alarm Phase Protection Alarm R BV20 Off On
Safety_Sts Safety Input Status R BV21 Normal Alarm
Occupied Occupied Mode Status R BV22 Off On
Occupied_BMS
Occupied Mode BMS - Sets Unit Occupancy when OccMode_Sel
is set to 2=BMS
R/W BV23 Off Off On
SF_Cmd Supply Fan Command R BV24 Off On
SF_Sts Supply Fan Status R BV25 Off On
Spc_Clg_Md Space Cooling Mode R BV26 Off On
Spc_Dehum_Md Space Dehum Mode R BV27 Off On
Spc_Htg_Md Space Heating Mode R BV28 Off On
Filter_Sts Main or ERV Dirty Filter Status R BV29 Off On
RH_Cmd Reheat Compressor Command R BV30 Off On
Spc_HtgClg_Md Space Heating Cooling Mode R BV31 Off On
Htr_1_Sts Gas Heater 1 Status R BV32 Off On
Htr_2_Sts Gas Heater 2 Status R BV33 Off On
