Reznor RCB - Page 39

Form CP-MAPSIII-D21, Doc No 303070, Page 39
Option D21 Lon Point List
Analog Variables
Name Description R/W Index Name NV Bit# TypeNV Unit Default Min Max
CC_Temp Cooling Coil Discharge Air Temp R 1 nvoCC_Temp SNVT_temp_p Deg F/C
DA_NAClg_SP Discharge Air Temp Neutral Cooling SP R/W 2 nviDA_NAClg_SP SNVT_temp_p Deg F/C 70/21.1 50/10 100/37.7
DA_NAHtg_SP Discharge Air Temp Neutral Heating SP R/W 3 nviDA_NAHtg_SP SNVT_temp_p Deg F/C 70/21.1 50/10 140/60
DA_SP Discharge Air Temp Active SP R 4 nvoDA_SP SNVT_temp_p Deg F/C
DA_SpcClg_SP Discharge Air Temp Space Cooling SP R/W 5 nviDA_SpcClg_SP SNVT_temp_p Deg F/C 55/12.7 50/10 100/37.7
DA_SpcHtCl_SP
Discharge Air Temp Space Heat Mode
Cooling SP
R/W 6 nviDA_SpcHtCl_SP SNVT_temp_p Deg F/C 55/12.7 50/10 100/37.7
DA_SpcHtg_SP Discharge Air Temp Space Heating Sp R/W 7 nviDA_SpcHtg_SP SNVT_temp_p Deg F/C 90/32.2 50/10 140/60
DA_Temp Discharge Air Temp R 8 nvoDA_Temp SNVT_temp_p Deg F
Damper_Cmd Damper Output Command R 9 nvoDamper_Cmd
SNVT_lev_
percent
% 0 100
DhOADP_SP Dehum OA Dew Point SP R/W 10 nviDhOADP_SP SNVT_temp_p Deg F/C 58/14.4 50/10 100/37.7
Ext_Dmpr_Cmd External Unit Damper Command R 11 nvoExt_Dmpr_Cmd
SNVT_lev_
percent
% 0 100
HX1_Mod_Cmd Heating 1 Modulation Command R 12 nvoHX1_Mod_Cmd
SNVT_lev_
percent
% 0 100
HX2_Mod_Cmd Heating 2 Modulation Command R 13 nvoHX2_Mod_Cmd
SNVT_lev_
percent
% 0 100
MA_Temp Mixed Air Temp R 14 nvoMA_Temp SNVT_temp_p Deg F/C
OA_Dew_Point Outside Air Dew Point R 15 nvoOA_Dew_Point SNVT_temp_p Deg F/C
OA_Hum_BMS
1
Outside Air Humidity BMS -Sets OA
Humidity when OA_Hum_Sel is set to
1=BMS
R/W 16 nviOA_Hum_BMS
SNVT_lev_
percent
%rH
OA_Hum_Raw Outside Air Humidity R 17 nvoOA_Hum_Raw
SNVT_lev_
percent
%rH
OA_Temp_BMS
Outside Air Temp BMS - Sets OA Temp
when OA_Temp_Sel is set to 1=BMS
R/W 18 nviOA_Temp_BMS SNVT_temp_p Deg F/C
OA_Temp_Raw Outside Air Temp R 19 nvoOA_Temp_Raw SNVT_temp_p Deg F/C
OAChgOv_SP OA Change Over SP R/W 20 nviOAChgOv_SP SNVT_temp_p Deg F/C 65/18.3 45/7.2 80/26.6
RH_Mod_Out Reheat Modulation Output % R 21 nvoRH_Mod_Out
SNVT_lev_
percent
% 0 100
SF_VFD_Cmd Supply Fan VFD Command R 22 nvoSF_VFD_Cmd
SNVT_lev_
percent
% 0 100
SpcEffClgSP Space Effective Cooling SP R 23 nvoSpcEffClgSP SNVT_temp_p Deg F/C
SpcEffHtgSP Space Effective Heating SP R 24 nvoSpcEffHtgSP SNVT_temp_p Deg F/C
Spc_Temp Space Temp R 25 nvoSpc_Temp SNVT_temp_p Deg F/C
SpcTempSP Space Temp SP R/W 26 nviSpcTempSP SNVT_temp_p Deg F/C 72/22.2 65/18.3 85/29.4
RA_Temp Return Air Temperature R 27 nvoRA_Temp SNVT_temp_p Deg F/C
RA_Humidity Return Air Humidity R 28 nvoRA_Humidity
SNVT_lev_
percent
%rH
EA_Temp Exhaust Air Temperature R 29 nvoEA_Temp SNVT_temp_p Deg F/C
EA_Humidity Exhaust Air Humidity R 30 nvoEA_Humidity
SNVT_lev_
percent
%rH
LONworks
®
Point List
8.0 Communication Cards (Cont’d)
8.2 LonWorks
®
(Option BHB7) Communication (Cont’d)
