Form CP-MAPSIII-D21, Doc No 303070, Page 41
Digital
Variables
Digital Inputs
Name Description R/W Index Name NV Bit# TypeNV Unit Default Min Max
Ext_OCC Occupied Mode Input R nvoDiStat1 0 SNVT_state Off On
Ext_Switch_1 External Damper Position Sw 1 R nvoDiStat1 1 SNVT_state Off On
Ext_Switch_2 External Damper Position Sw 2 R nvoDiStat1 2 SNVT_state Off On
Htr_1_Sts Gas Heater 1 Status R nvoDiStat1 3 SNVT_state Off On
Htr_2_Sts Gas Heater 2 Status R nvoDiStat1 4 SNVT_state Off On
Phase_Alarm Phase Protection Alarm R nvoDiStat1 5 SNVT_state Off On
Safety_Sts Safety Input Status R nvoDiStat1 6 SNVT_state Normal Alarm
SF_Sts Supply Fan Status R nvoDiStat1 7 SNVT_state Off On
Filter_Sts Main or ERV Dirty Filter Status R nvoDiStat1 8 SNVT_state Off On
Digital
Variables
Unit Modes
Name Description R/W Index Name NV Bit# TypeNV Unit Default Min Max
NA_Clg_Md Neutral Air Cooling Mode R nvoMdStat1 0 SNVT_state Off On
NA_Dehum_Md Neutral Air Dehum Mode R nvoMdStat1 1 SNVT_state Off On
NA_Htg_Md Neutral Air Heating Mode R nvoMdStat1 2 SNVT_state Off On
Spc_Clg_Md Space Cooling Mode R nvoMdStat1 3 SNVT_state Off On
Spc_Dehum_Md Space Dehum Mode R nvoMdStat1 4 SNVT_state Off On
Spc_Htg_Md Space Heating Mode R nvoMdStat1 5 SNVT_state Off On
Spc_HtgClg_Md Space Heating Cooling Mode R nvoMdStat1 6 SNVT_state Off On
8.0 Communication Cards (Cont’d)
8.2 LonWorks
®
(Option BHB7) Communication (Cont’d)
LONworks
®
Point List (Cont’d)
