Chapter 4 – Specifications
9450 Duolink Exit Alarm Receiver Hardware Installation Guide Page 27 of 30
0510-1103-G
Chapter 4 – Specifications
This section contains information on the specifications for the DuoLink
Exit Alarm Receiver, including details about the specific requirements and
certifications.
Dimensions
12.2” L x 1.7” D x 1.3” W
Weight
5.75 oz
Color
Off-White
Composition
Polycarbonate
Power
12 VDC from the Exit Controller
Wiring Interface
4-pin locking connector
Frequency Selection
66 kHz or 262 kHz
LED Colors
Illuminates red for 66 kHz and green for 262 kHz
Operating Temperature
32-140°F
Range
The designed range is 4 feet. The adjustable range surrounding the
antenna location is up to an 8 feet radius, depending on the RF
environment.
Certifications
UL Standard 294
Part Number(s)
9450-0170K
9450 DuoLink Antenna Kit
Additional Part Number(s)
0120-0062K
Code Alert Mounting Block & Hardware Kit
