RGBlink RMS 8424S User Manual

RMS 8424S User Manual
Number of Inputs
2
Connector
Standard DB15 Socket
Supported Standard
VGA-UXGA
Signal Level
R, G, B, Hsync, Vsync: 0 to1Vpp±3dB (0.7V Video+0.3v Sync ) 75 ohm
black level: 300mV Sync-tip: 0V
Supported Resolution
640x480@60|800x600@60|1024x768@60|1280x1204@60|
1600x1200@60|1920x1200@60
DVI Loop Out
Number of Loop Out
2
Connector
Standard DVI-I socket
Supported Resolution
SMPTE：480i@60|480p@60|576p@50|720p@50/60|1080i@@50/60
1080p@50/60
VESA：640x480@60|800x600@60|1024x768@60
1280x1204@60|1440x1440@60|1440x1530@60|1523x1536@60
1600x1200@60|1920x1200@60|2048x1152@60|2560x816@60
2688x896@60|2700x1000@60|2800x990@60|2900x959@60
2986x931@60|3840x670@60|3840x733@60
Signal Level
TMDS pwl, single pixel input,165MHz bandwidth
Format Standard
HDMI 1.3
SDI Loop Out
Number of Loop Out
2
Connector
Standard BNC Socket
Data Rate
2.97Gb/s, 2.97/1.001Gb/s, 1.485Gb/s, 1.485/1.001Gb/s and 270Mb/s
Supported Standard
SMPTE 422, SMPTE 259M-C, SMPTE 292M
Supported Resolution
480i@60 | 576i@50 | 720p@50/60 | 1080i@@50/60 | 1080p@50/60
Extras
Power
5.4mm DC Socket
Max Power
24W
Temperature
0°C~40°C
Humidity
10% to 85%
Product Warranty
3 years parts and labor warranty

RGBlink RMS 8424S Specifications

General

Brand	RGBlink
Model	RMS 8424S
Category	Monitor
Language	English
