Chapter 6 Appendix
6.1 Specification
LCD Displays
Size
8”
Native Resolution
1024x600px
Native Display Ratio
16:9
Contrast
700:1
Viewing Angle
140°x140°
Brightness (max)
500cd/m
2
Display Refresh
15KHz – 120KHz
CVBS Input
Number of Inputs
2
Connector
Standard BNC Socket
Supported Standards
PAL/NTSC
Signal Level
1Vpp±3db (0.7V Video+0.3v Sync ) 75 ohm
Multiplex
480i,576i
3G-SDI Input
Number of Inputs
2
Connector
Standard BNC Socket
Data Rate
2.97Gb/s, 2.97/1.001Gb/s, 1.485Gb/s, 1.485/1.001Gb/s and 270Mb/s
Supported Standard
SMPTE 422, SMPTE 259M-C, SMPTE 292M
Supported Resolution
480i@60 | 576i@50 | 720p@50/60 | 1080i@@50/60 | 1080p@50/60
Balance
Belden 1694A cable:
150m at 2.97Gb/s
250m at 1.485Gb/s
480m at 270Mb/s
DVI Input
Number of Inputs
2
Connector
Standard DVI-I socket
Supported Resolution
SMPTE：480i@60|480p@60|576p@50|720p@50/60|1080i@@50/60
1080p@50/60
VESA：640x480@60|800x600@60|1024x768@60
1280x1204@60|1440x1440@60|1440x1530@60|1523x1536@60
1600x1200@60|1920x1200@60|2048x1152@60|2560x816@60
2688x896@60|2700x1000@60|2800x990@60|2900x959@60
2986x931@60|3840x670@60|3840x733@60
Signal Level
TMDS pwl, single pixel input,165MHz bandwidth
Format Standard
HDMI 1.3
VGA Input
