Setting Up
22
2
L Close the inner cover. Lock the in-
ner cover by pressing in ( ) and
then turning the two green levers
clockwise ( ).
M Close the left cover.
Close the left cover firmly using
both hands, until it clicks into
place.
N Open the top cover by grasping
the handles on the left and right
sides.
O
Remove the clips protecting the
mouths of all four toner cartridges.
P Close the top cover.
Q Put labels “1” on the front of the
paper tray.
R Attach the supplied sticker, which
warns users that ink-jet printer pa-
per cannot be use with this print-
er, to the front of the machine.
AET017S
AET009S
AET029S
AET032S
AET030S
GaiaP1GB_Setup-F4_FM_forPaper.book Page 22 Friday, June 3, 2005 7:50 AM
