Ricoh Aficio SP 5210DN - Page 198

5. Pull out the misfed paper by holding both sides of paper. Be careful not to get toner dust on
your hands or clothes.
1
2
CEC080
6. Hold the grips of the print cartridge, and then push it into the printer until it stops.
CEC028
7. Close the front cover.
CEC214
10. Removing Misfed Paper
196
10
