4. Press the [Menu] key to return to the initial screen.
5. Print a configuration page to confirm the settings.
• The SSID can also be set using a Web browser. For details, see Web Image Monitor Help.
• For details about printing the configuration page, see p.44 "Test Printing".
Confirming Wireless Network Connectivity
After you have installed the Wireless LAN interface unit, use the following procedure to check for Wireless
LAN connectivity.
Make sure the LED on the Wireless LAN interface unit is lit.
CEC077
1
2
1
2
1. If the Wireless LAN unit is receiving power, the upper indicator will be lit green.
2. If the printer is connected to an operational network and is communicating normally, the lower
indicator will be lit orange.
Cautions When Using a Wireless LAN
A Wireless LAN uses radio waves instead of cables to send and receive data. Because radio waves usually
pass through walls and other obstructions, the following problems may arise if you do not configure wireless
security settings.
Information leakage
Information such as IDs, passwords, credit card numbers, and e-mail content may be seen by an
unauthorized 3rd party.
Unauthorized network access
• Damage to or alteration of data and/or system configurations by viruses or other malware.
• Impersonation of legitimate network users, resulting in data theft.
• Theft of sensitive or confidential data.
Wireless LAN Configuration
87
5

Ricoh Aficio SP 5210DN Specifications

General

Color	No
Duplex printing	-
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Printing colors	Black
Maximum duty cycle	200000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	650 sheets
Maximum input capacity	2850 sheets
Multi-Purpose tray input capacity	100 sheets
Duplex media weight	60 - 163 g/m²
Paper tray media types	Labels, Plain paper, Pre-Printed, Recycled paper, Thick paper
Paper tray media weight	52 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP (IPv4, IPv6), IPX/SPX, Apple Talk, Bonjour
Standard interfaces	Ethernet, USB 2.0
Product color	White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (printing)	- W
Power consumption (PowerSave)	5 W
Sustainability certificates	ENERGY STAR
Server operating systems supported	Windows Server 2003, Windows Server 2008

Weight and Dimensions

Depth	435 mm
Width	411 mm
Height	400 mm
