The keys you can select are as follows:
• [Frequent]: Added to the page that is displayed first.
• [AB], [CD], [EF], [GH], [IJK], [LMN], [OPQ], [RST], [UVW], [XYZ], [1] to [10]: Added to the
list of items in the selected title.
You can select [Frequent] and one more key for each title.
9. Press [Auth. Info], and then press [ Next].
10. Press [Specify Other Auth. Info] on the right side of "Folder Authentication".
When [Do not Specify] is selected, the SMB User Name and SMB Password that you have
specified in "Default User Name / Password (Send)" of File Transfer settings are applied.
11. Press [Change] under "Login User Name".
12. Enter the login user name of the destination computer, and then press [OK].
13. Press [Change] under "Login Password".
14. Enter the password of the destination computer, and then press [OK].
15. Enter the password again to confirm, and then press [OK].
16. Press [Folder].
17. Check that [SMB] is selected.
18. Press [Change] or [Browse Network], and then specify the folder.
To specify a folder, you can either enter the path manually or locate the folder by browsing the
network.
Basic Procedure When Using Scan to Folder
87

Ricoh MP C2011 Specifications

General

Print Technology	Laser
Print Speed (Black)	20 ppm
Print Speed (Color)	20 ppm
Max Print Resolution	1200 x 1200 dpi
Copy Speed (Black)	20 cpm
Copy Speed (Color)	20 cpm
Copy Resolution	600 dpi
Multiple Copy	Up to 999 copies
Paper Output	250 sheets
Duplex Printing	Yes
Processor	600 MHz
Memory (Standard)	1.5 GB
Memory (Maximum)	1.5 GB
Hard Disk Drive (Optional)	250 GB
Power Source	220-240V, 50/60Hz
Fax Transmission Speed	33.6 kbps
Max Paper Size	A3
Network Connectivity	Ethernet
Scan Resolution	600 dpi
Functions	Print, Copy, Scan
Zoom	25% to 400%
Scan Speed (Black)	54 ipm
Scan Destinations	Email, Folder, USB
Paper Sizes	A3, A4, A5, B4, B5
Interface	USB 2.0, Ethernet
Network Protocol	TCP/IP, IPv4, IPv6
Operating System Compatibility	Windows, Mac, Linux
First Print Time (Color)	11 seconds or less
