19. Press [Connection Test] to check the path is set correctly.
20. Press [Exit].
If the connection test fails, check the settings, and then try again.
21. Press [OK].
22. Press [Exit].
23. Press the [User Tools/Counter] key.
Locating the SMB folder manually
1. Press [Change] under "Path".
2. Enter the path where the folder is located.
For example: if the name of the destination computer is "User", and the folder name is "Share", the
path will be \\User\Share.
If the network does not allow automatic obtaining of IP addresses, include the destination
computer's IP address in the path. For example: if the IP address of the destination computer is
"192.168.0.191", and the folder name is "Share", the path will be \\192.168.0.191\Share.
3. Press [OK].
If the format of the entered path is not correct, a message appears. Press [Exit], and then enter the
path again.
Locating the SMB folder using Browse Network
1. Press [Browse Network].
The client computers sharing the same network as the machine appear.
Network display only lists client computers you are authorized to access.
2. Select the group that contains the destination computer.
5. Scan
88

Ricoh MP C2011 Specifications

General

Print Technology	Laser
Print Speed (Black)	20 ppm
Print Speed (Color)	20 ppm
Max Print Resolution	1200 x 1200 dpi
Copy Speed (Black)	20 cpm
Copy Speed (Color)	20 cpm
Copy Resolution	600 dpi
Multiple Copy	Up to 999 copies
Paper Output	250 sheets
Duplex Printing	Yes
Processor	600 MHz
Memory (Standard)	1.5 GB
Memory (Maximum)	1.5 GB
Hard Disk Drive (Optional)	250 GB
Power Source	220-240V, 50/60Hz
Fax Transmission Speed	33.6 kbps
Max Paper Size	A3
Network Connectivity	Ethernet
Scan Resolution	600 dpi
Functions	Print, Copy, Scan
Zoom	25% to 400%
Scan Speed (Black)	54 ipm
Scan Destinations	Email, Folder, USB
Paper Sizes	A3, A4, A5, B4, B5
Interface	USB 2.0, Ethernet
Network Protocol	TCP/IP, IPv4, IPv6
Operating System Compatibility	Windows, Mac, Linux
First Print Time (Color)	11 seconds or less
