Ricoh Nashuatec CP430 - Image Adjustment Procedures

31 October 2001 SCANNER
3-9
Replacement
Adjustment
3.3.6 IMAGE ADJUSTMENT
Purpose: To adjust the image position on prints by changing the SP settings.
Adjust the following in the order given below.
SP6-10: Master writing speed (☛ 5.7.3)
↓
SP6-21: Paper registration position (☛ 5.7.3)
↓
SP6-05: Scanning speed - platen (☛ 5.7.3)
SP6-06: Scanning speed - ADF
↓
SP6-03: Scanning start position - platen (☛ 5.7.3)
SP6-04: Scanning start position - ADF
↓
SP6-01: Main scan position - platen (☛ 5.7.3)
SP6-02: Main scan position - ADF
↓
SP6-31: SBU calibration (☛ 5.7.4)
