31 October 2001 MAIN MENU NO.2: BASIC SETTINGS
5-5
Service
Tables
5.3 MAIN MENU NO.2: BASIC SETTINGS
5.3.1 SP TABLE
No. Menu Items Default Settings
2-1 Default print speed 3 1 to 5
2-2 Default image position 4 1 to 7
1: -15mm, 2: -10mm, 3: -5mm,
4: 0.0mm, 5: +5mm, 6: +10mm,
7: +15mm
2-10 Ink detection board On Off/On (Off is used for tests, and
for removing ink from the drum –
section 3.8.)
2-11 Paper end sensor On Off/On (Off is used for tests.)
2-12 Drum master sensor On Off/On (Off is used for tests.)
2-13 Platen cover sensor On Off/On (Off is used for tests.)
2-14 ADF cover sensor On Off/On (Off is used for tests.)
2-20 Destination setting - 0: Japan, 1: NA, 2: EU
2-21 Swap start key for print key Off Off/On
2-22 Double count-up for A3 masters 0 0: Not used, 1: Master counter
only, 2: Master counter and print
counter
2-40 T/H energy control by ink temperature On Off/On
2-41 Thermal head energy control 7 0 to 50%
2-42 Thermal head energy control - economy 10 0 to 43% (☛ 5.3.2)
5.3.2 SP2-41, 2-42: THERMAL HEAD ENERGY CONTROL
2-41: The default is 7%. This means that during normal printing mode, the thermal
head energy is 93% of the maximum possible (100 – 7).
2-42: The default is 10%. This means that in economy printing mode, the thermal
head energy is reduced by another 10%. With the default settings, this
means that the thermal head energy is 83% of maximum power (100-7-10).
