31 October 2001 MAIN MENU NO.4: INPUT MODE
5-7
Service
Tables
5.5 MAIN MENU NO.4: INPUT MODE
5.5.1 SP TABLE
No. Menu Items No. Menu Items
4-1 Scanner HP sensor 4-41 Registration sensor
4-2 Platen cover sensor 4-42 Feed start timing sensor
4-43 2nd feed timing sensor
4-10 Master making unit set switch 4-44 Paper exit sensor
4-11 Master set cover sensor
4-12 Cutter HP sensor 4-50 Door safety switch
4-13 Master end sensor
4-14 Eject box set switch 4-60 ADF connecting signal
4-15 Master eject sensor 4-61 ADF cover sensor
4-16 Pressure plate HP sensor 4-62 ADF registration sensor
4-17 Pressure plate limit sensor 4-63 ADF original trailing edge sensor
4-18 Ink detection signal 4-64 ADF original set sensor
4-19 Color drum signal 4-65 ADF original length sensor 1
4-20 Drum size signal 4-66 ADF original length sensor 2
4-21 Drum set signal 4-67 ADF original width sensor 1
4-22 Clamper open sensor 4-68 ADF original width sensor 2
4-23 Clamper closed sensor 4-69 ADF open sensor
4-24 Drum master sensor
4-25 Master eject position (drum HP) sensor 4-70 Optional key counter signal
4-26 Paper exit timing sensor
4-30 Table lowering switch
4-31 Table lower sensor
4-32 Paper height sensor
4-33 Paper end sensor
4-34 Paper length sensor
4-35 Paper width signal 0
4-36 Paper width signal 1
4-37 Paper width signal 2
4-38 Paper width signal 3
4-39 Paper width signal 4
4-40 Paper width signal 5
