Ricoh P 501 User Manual

8. Close the rear cover with both hands carefully. Be careful not to trap your fingers.
DYR194
Paper Misfeed Message (Y1) to (Y3)
The following messages are displayed according to the tray where the paper is jammed:
• " (Y1)": Tray 2
• " (Y2)": Tray 3
• " (Y3)": Tray 4
The procedure for removing jammed paper is the same for all trays. In the following procedure, a paper
jam that occurs in Tray 2 (with the (Y1) message displayed) is explained as an example.
1. Pull out the paper tray until it stops.
DYQ139
Removing Jammed Paper
123

Ricoh P 501 Specifications

General

Print Technology	Laser
Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Connectivity	USB 2.0, Ethernet
Duplex Printing	Yes
Media Type	Plain paper, Recycled paper
Supported Operating Systems	Windows, Linux
Print Speed	Up to 45 ppm
