Technical Bulletin PAGE: 2/5
SOLUTION
Connect the spring pin to the coupling with the following procedure. The procedure is the
same for the paper feed belt unit of the main machine and of the Vacuum Feed LCIT
RT5100, and can be performed either when the main power switch is turned ON or OFF.
Procedure when the main power switch is ON
1. With the paper feed belt unit [A] installed, pull out the tray(s) showing the symptom
and check if there is a gap between the frames at the location indicated with the red
dotted circle.
If there is no gap, do Step 5.
If there is a gap, do Steps 2 through 5.
To Next Page
