Ricoh Pro C7100

Technical Bulletin PAGE: 3/5
Model: Vacuum Feed LCIT
Date: 30-Nov-15
No.: RD777005
2. Close the tray.
3. Execute the SP for the tray(s) showing the symptom. This will rotate the paper feed
belt for 5 seconds so that the spring pin connects with the coupling.
 SP5-805-100 (Output Check: LCT1: Paper Feed Belt Motor: Tray3)
 SP5-805-114 (Output Check: LCT1: Paper Feed Belt Motor: Tray4)
 SP5-805-131 (Output Check: LCT2: Paper Feed Belt Motor: Tray5)
 SP5-805-145 (Output Check: LCT2: Paper Feed Belt Motor: Tray6)
 SP5-805-162 (Output Check: LCT3: Paper Feed Belt Motor: Tray7)
 SP5-805-176 (Output Check: LCT3: Paper Feed Belt Motor: Tray8)
4. Pull out the tray and confirm that there is no gap between the frames.
5. Confirm that the two screws fixing the paper feed belt unit are tightly fastened.
