6. Main power indicator
The main power indicator goes on when you turn on the main power switch.
7. Operation switch
Press to turn the power on (the operation switch indicator lights up). To turn the power off, press again (the
operation switch indicator goes off). See “Turning On/Off the Power”.
8. Paper tray (tray 1, 2)
Load paper here.
9. Main power switch
If the machine does not operate after turning on the operation switch, check if the main power switch is turned
on. If it is off, turn it on. See “Turning On/Off the Power”.
1. Ventilation holes
Prevent overheating.
2. Earth breakers
Main breaker (top): Cuts the flow of electricity from the main power supply if a current overload occurs.
Heater breaker (bottom): Cuts the flow of electricity to the heater if a current overload occurs.
• p.39 "Control Panel"
• p.48 "Turning On/Off the Power"
1. Getting Started
36
