Specifications for Wide Large Capacity Tray
This section describes specifications for the Wide LCT.
To connect two Wide LCTs, a bridge unit is required.
Paper size:
SRA3 , A3 , B4 JIS , A4 , B5 JIS , A5 ,
12 × 18 , 11 × 17 , 11 × 15 , 11 × 14 , 10 × 15 , 10 × 14 , 8
1
/
2
× 14 , 8
1
/
2
× 13
, 8
1
/
2
× 11 , 8
1
/
4
× 14 , 8
1
/
4
× 13 , 8 × 13 , 8 × 10 , 5
1
/
2
× 8
1
/
2
, 7
1
/
4
×
10
1
/
2
Custom size:
• Vertical: 139.7 330.2 mm (5.50 13.00 inches)
• Horizontal: 182.0 487.7 mm (7.17 19.20 inches)
Paper weight:
60 300 g/m
2
(16 lb. Bond 110 lb. Cover)
Paper capacity (80 g/m
2
, 20 lb. Bond):
4,400 sheets
Power consumption:
Maximum 240 W (Power is supplied from the main unit.)
Dimensions (W × D × H):
965 × 735 × 980 mm (38.0 × 29.0 × 38.6 inches)
Weight:
Approx. 200 kg (441 lb.)
Specifications for Wide Large Capacity Tray
81
